XIOMLANGUAGE SPECIFICATION

1. Overview & Core Goals

A language specification describes what the language means. It does not imply that every property of every program is formally proven.

XIOM is a compiled, statically typed, memory-safe systems programming language. It is designed around three properties that no existing mainstream language provides simultaneously:

SAFE	Ownership-based memory safety with no garbage collector and no mandatory managed runtime. Memory is freed deterministically when the owner leaves scope.
VERIFIED	Pre-conditions, post-conditions, and type invariants are first-class language constructs: enforced at runtime today, and available to verification tooling for supported properties. Runtime checking and formal verification are distinct mechanisms.
PRECISE	The grammar is unambiguous. Every construct has exactly one canonical form. No implicit coercions; allocation is explicit in the language model, and library operations document when they allocate.

XIOM compiles to native machine code via LLVM and to WebAssembly as a co-equal target. Self-hosting gates are cleared, but no self-hosted release has shipped; the released toolchain is the bootstrap compiler.

Status of this revision: it defines the core language. The current implementation surface, compiler flags, platform behavior and toolchain features are documented separately in the language documentation and are not part of this revision.

2. Design Principles

2.1 Canonical Syntax and Explicit Semantics

Every construct has exactly one canonical syntax. Formatting is part of the language specification. The canonical formatter (xiom fmt) is part of the compiler toolchain.

2.2 Explicit Over Implicit

Nothing happens without being written. Memory allocation is visible. Type conversions are explicit. If a function can fail, its return type says so. If a value can be absent, its type says so.

2.3 Contracts Are Specification

Contracts (requires, ensures, invariant) are not assert statements. They are formal specifications that the compiler reasons about. At minimum they compile to checked runtime guards with precise error messages.

2.4 No Null

The language has no null, nil, or undefined value. Absence is expressed through Option[T]. The compiler enforces exhaustive handling of the absent case at every use site.

2.5 Errors Are Types

Functions that can fail return Result[T, E]. There are no exceptions. The ? operator propagates errors explicitly.

2.6 Structural Interfaces

A type satisfies an interface if it has the required fields and methods. No implements declaration is needed.

2.7 Comptime Is the Only Metaprogramming

There is no preprocessor, no macro system, and no template language. All compile-time code generation uses comptime.

2.8 Derive -- Compiler-Generated Correctness

For common interfaces (Eq, Clone, Display, Hash, Ord), the programmer declares intent and the compiler generates the implementation. The generated code is always correct by construction.

3. Syntax Preview

Variables

let x: Int = 42           // immutable binding
var y: Float64 = 3.14     // mutable binding
let name = "XIOM"        // type inferred

Functions with Contracts

fn divide(a: Float64, b: Float64) -> Float64
  requires: b != 0.0
  ensures:  result * b == a
{
  return a / b
}

Types with Derive

type Point = {
  x: Float64;
  y: Float64;
} derive[Eq, Clone, Display]

// Compiler generates eq(), clone(), to_str() automatically

Generics with Inline Constraints

fn max[T: Comparable](a: T, b: T) -> T {
  if a > b { return a }
  return b
}

let m = max(10, 20)   // T = Int, inferred

Algebraic Types

enum AgentState {
  Idle,
  Patrolling(route: Vec[Vector3]),
  Attacking(target: EntityId),
  Dead(cause: DamageCause),
}

Error Handling

fn loadFile(path: Str) -> Result[File, IOError] {
  let f = open(path)?   // ? propagates error up
  return Ok(f)
}

match loadFile("data.bin") {
  Ok(file)  => process(file),
  Err(e)    => log.error(e.message),
}

Methods with Implicit Self

pub fn Vec3.dot(other: &Vec3) -> Float32 {
  return x * other.x + y * other.y + z * other.z
  // self is implicit -- fields accessed directly
}

Structural Interfaces

interface Comparable {
  fn compare(other: &Self) -> Int
}

type Score = { value: Int }

fn Score.compare(other: &Score) -> Int {
  if value < other.value { return -1 }
  if value > other.value { return  1 }
  return 0
}
// Score satisfies Comparable -- no implements keyword needed

4. Primitive Types

Type	Width	Description
Bool	1 bit	Only true or false. No integer coercion.
Int	Platform (64-bit)	Signed. Default integer type.
Int8-Int128	8-128 bits	Explicit-width signed integers, including Int128; integer literals beyond 64 bits are supported.
UInt	Platform (64-bit)	Unsigned. Use for sizes and indices.
UInt8-UInt128	8-128 bits	Explicit-width unsigned integers, including UInt128. UInt8 is aliased as Byte.
Float32, Float64	IEEE 754 single / double	Float64 is the default float type. Float128 is produced by conversion and has no literal suffix.
Char	32 bits	Unicode scalar value. Not a byte.
Str	Fat pointer	Immutable UTF-8 slice. Not null-terminated.

Compound Types

Type	Description
Option[T]	Either Some(value) or None. Replaces null.
Result[T, E]	Either Ok(value) or Err(error). Replaces exceptions.
Vec[T]	Heap-allocated growable array.
Map[K, V]	Hash map. K must satisfy Hash and Eq.
Set[T]	Hash set. T must satisfy Hash and Eq.
(T, U, ...)	Tuple. Fixed arity, mixed types.
*T	Raw pointer. Only usable inside unsafe blocks.

5. Memory Model

XIOM uses ownership semantics for memory management. There is no garbage collector. Memory is freed when the owning binding leaves its scope. The model uses lexical scope borrowing: borrows are validated from scope nesting alone, without Rust-style lifetime annotations. This is a design choice, not a claim that the two languages have identical semantics.

Ownership Rules

Rule	Description
Single Owner	Every value has exactly one owner at any time. Assignment moves ownership.
Scope Lifetime	A value is freed when its owning binding leaves scope.
Read Borrow (&T)	Multiple simultaneous read borrows allowed. No mutation.
Write Borrow (&mut T)	Exactly one write borrow at a time. No other borrows.
Explicit Clone	Duplicating requires .clone(). No implicit deep copy.
Move On Call	Passing a value to a function moves ownership unless the parameter is a borrow.

Borrows cannot be stored in struct fields. Borrows cannot be returned from functions. This is a constraint, not a bug -- it is the design.

fn consume(data: Vec[Int]) { }          // takes ownership
fn read_only(data: &Vec[Int]) { }         // read borrow
fn mutate(data: &mut Vec[Int]) { }       // write borrow

let v = [1, 2, 3]
read_only(&v)        // borrow, v still valid
mutate(&mut v)       // write borrow, v still valid
consume(v)           // move -- v no longer usable

6. Contract System

Contracts are part of the language: pre-conditions, post-conditions and type invariants. They compile to runtime guards by default, and supported properties can be exported to verification tooling. Runtime checking and formal verification are different mechanisms, and a contract in the source is not by itself a proof.

Keywords

Keyword	Semantics
requires	Pre-condition. Must hold when the function is called. Caller is responsible.
ensures	Post-condition. Must hold when the function returns. Implementation is responsible.
invariant	Type-level contract. Must hold after every mutation of a value of this type; enforcement coverage in the current compiler is partial.
result	Refers to the return value inside an ensures clause.
self@pre	Value of self at the moment the function was entered.

Type Invariants

type Health = {
  current: Int;
  maximum: Int;
  invariant: current >= 0;
  invariant: current <= maximum;
  invariant: maximum > 0;
}
// The compiler rejects any code that could violate these invariants.

Contract Collection Methods

Method	Meaning
.is_sorted()	Elements are in non-decreasing order
.all(closure)	All elements satisfy the predicate
.none(closure)	No element satisfies the predicate
.contains(value)	Collection contains the given value

7. Target Platforms

Target	Path
x86_64 Windows / Linux / macOS	XIOM -> LLVM -> native
aarch64 macOS / iOS / Android	XIOM -> LLVM -> native
riscv64 Linux	XIOM -> LLVM -> native
WASM (browsers, Node.js, edge, WASI)	XIOM -> LLVM -> WASM32

GPU and console targets are library concerns accessed through C FFI -- they are not language features.

8. Non-Normative Material

Language comparisons, benchmark methodology and trade-off discussions are documentation, not specification. They live on the Prior art and trade-offs page and the Why XIOM page, and do not define the language.
